The ProSafe FS installs easily and does not require a dedicated monitor to verify the operational status of the galvanic isolator, as required by non FailSafe Certified galvanic isolators.
Built on robust FlatPack semiconductor platforms, ProSafe FS 30 & 60 ensure that in the event of a failure, the failure is safe by not compromising the ground continuity on-board when connected to AC Shore Power.
Compliant with ABYC A-28 July '08 and Fail Safe Certified by Underwriters Laboratories (UL), it maintains the shore power safety ground wire through the isolator.
The UL Certified 205007 Flat Pack High Power Semiconductors feature robust high power diodes that allow the FS Series to meet the new FailSafe criteria for conducting inrush currents of 3,000 amps for the required duration period.
Ignition Protected, it meets ISO 8846 and can be mounted within an engine compartment.
Specifications include Shore Cord Inlet Compatibility for Single 15, 16, 20 or 30 Ratings VAC / Max Amps / Hz: 120/240 VAC / 41 Amps / 50 or 60 Hz, Max Temperature: 50° C, Size L x W x H: 6.75" x 7" x 2.5", and Weight: 3 lbs.
