Home / Automotive / Replacement Parts / Body

Break Pedal Assembly WILWOOD 34011299

$301.36 USD

✓ No hidden fees — taxes included in the price & Free Shipping.

✓
Get 5% OFF Today
Use this coupon at checkout.
TRY5
Brand : Wilwood
WILWOOD 34011299 Break Pedal Assembly combines brake and clutch pedals in one unit.
Out of stock
Quantity :
Top Brands. Best Prices. Fast Shipping.

Discover quality parts and accessories for every adventure

Shop now before stocks run out — smart shoppers move fast!

Explore Now

Product Comparison We Made Easy For You

Break Pedal Assembly WILWOOD 34011299
Break Pedal Assembly WILWOOD 34011299
View Detail
Type
Body
Title
Break Pedal Assembly WILWOOD 34011299
Price
$301.36 USD
Vendor
Wilwood
Description
This pedal assembly combines the brake and clutch pedals in one unit, with the master cylinders positioned in a reverse manner inside the firewall.It features a lightweight aluminum frame, with reinforced I-Beam style forged 6.25:1 ratio pedal arms of high strength.The non-skid waffled pedal pads can be adjusted laterally for driver preference or necessary clearance.The balance bar incorporates a positive detent stop every full turn to maintain the adjustment position and driver awareness.A pin and clevis pushrod attachment system provides the highest possible degree of misalignment angle for bind-free operation through the entire range of travel.The balance bar can be locked in place with the included jam nut or used with an optional rmte cable for quick adjustments on track.This pedal accepts any Wilwood vertical mount flange single outlet master cylinders that are ordered separately by style and bore size.

More about this item : Break Pedal Assembly WILWOOD 34011299

This pedal assembly combines the brake and clutch pedals in one unit, with the master cylinders positioned in a reverse manner inside the firewall.

It features a lightweight aluminum frame, with reinforced I-Beam style forged 6.25:1 ratio pedal arms of high strength.

The non-skid waffled pedal pads can be adjusted laterally for driver preference or necessary clearance.

The balance bar incorporates a positive detent stop every full turn to maintain the adjustment position and driver awareness.

A pin and clevis pushrod attachment system provides the highest possible degree of misalignment angle for bind-free operation through the entire range of travel.

The balance bar can be locked in place with the included jam nut or used with an optional rmte cable for quick adjustments on track.

This pedal accepts any Wilwood vertical mount flange single outlet master cylinders that are ordered separately by style and bore size.

Break Pedal Assembly WILWOOD 34011299
Key Features
  • With Balance Bar Adjustment
  • Mount Location: Firewall
  • Mount Facing: Reverse
  • Ratio: 6.25:1
  • Pedal Pads Allow Fine-Tuning
  • Includes Mounting Studs and Hardware
Technical Specifications
  • Length : 12.9 lb
  • Width : 10.5 lb
  • Height : 7.9 lb
  • Weight : 5.3 lb
Product Identifiers
  • ASIN B019XEW48O
  • UPC: 889545028393
Shipping Information
  • Ships From : United States
  • Brand : Wilwood

Frequently Asked Questions About : Break Pedal Assembly WILWOOD 34011299

01 What is the ratio of the pedal assembly?

The ratio is 6.25:1.

02 Where is the mount location for the pedal assembly?

The mount location is the firewall.

03 What type of master cylinders does this pedal assembly accept?

This pedal accepts any Wilwood vertical mount flange single outlet master cylinders.
