Sundown Audio X v.3 12" Subwoofer: Redefining Deep Bass Performance.
An astounding level of deep, impactful bass is unleashed with the Sundown Audio SW-XV312D1 X v.3 12" Subwoofer.
This cutting-edge 12-inch subwoofer is engineered meticulously to set a new industry standard in the low-frequency/small-ported-box category.
An array of advanced features combined with robust construction allows the X v.3 to deliver exceptional performance, remarkable power handling, and incredibly low distortion, making it the premier choice for enthusiasts seeking uncompromising audio quality in their vehicle.
Extreme Power Handling & Unmatched Excursion: Built for serious power, the X v.3 12" subwoofer handles a formidable 2500 Watts RMS and 5000 Watts Peak power.
This immense capacity ensures that the subwoofer can reproduce the most demanding low-frequency content with astonishing clarity and sustained output.
Designed with a hyper-extended pole piece and an incredible four inches of peak-to-peak excursion, it achieves an impressive 30mm of linear Xmax.
This allows for ultra-deep bass extension and dynamic output, even at high volumes, truly immersing you in your music.
Its Sensitivity (Sens) of 83.2dB indicates its efficiency in converting power to sound, while its Dual 1 Ohm voice coil configuration offers flexible wiring options.
Revolutionary Mega-Roll v.2 Surround & Linear Suspension: The X v.3 series differentiates itself with its incredibly linear suspension, guaranteeing the lowest level of bass extension possible in a small enclosure while maintaining extremely low levels of distortion.
A key component of this linearity is the all-new Mega-Roll v.2 Surround.
This improved design offers a more linear and rugged update to the world-famous Mega-Roll v.1, ensuring superior cone control and enhanced durability over extended periods of high excursion.
Advanced Motor Structure & Thermal Management: At the core of the X v.3's remarkable performance is its significantly larger triple-stacked 220mm magnet motor structure, a substantial improvement over previous versions (190mm on v.1 series).
This powerful motor, coupled with a robust 3" Voice Coil, provides exceptional control over the cone's movement.
Furthermore, the X v.3 incorporates improved motor ventilation, ensuring efficient heat dissipation and maintaining optimal operating temperatures even during demanding use.
This meticulous thermal management guarantees long-term reliability and consistent performance.
Optimized Enclosure Flexibility & Dimensions: Engineered to excel, the X v.3 is primarily optimized for 2.5 cu ft net ported enclosures with a recommended tuning of 32Hz and a port area of 40 sq in.
The X Series can also work in up to a 50% larger enclosure if you desire even more low-end extension, offering increased versatility.
Its Displacement of 0.2 cu ft and compact dimensions, including a Depth of 10.4", Outside Diameter of 12.68", and Cutout of 11.09", provide versatile installation options for a wide range of vehicles.
Physical dimensions from the drawing, such as a depth of 263.5mm (10.37") and an outside diameter of 322.0mm (12.68"), further illustrate its design.
Uncompromising Build Quality: The Sundown Audio X v.3 12" Subwoofer is built to last, featuring a heavy-duty cast basket and robust construction throughout.
Every component is meticulously designed to withstand the rigors of high-power audio reproduction, ensuring reliability and consistent performance for years to come.
This commitment to quality makes the X v.3 a truly durable and high-performance subwoofer, capable of delivering an unparalleled audio experience.
