The #19069 Reconditioned Edelbrock AVS2 Series carburetor 650 cfm is the next generation in Edelbrock carburetors.
Designed and calibrated for optimum street performance in small-block and some big-block engines.
The AVS2 features primary boosters with annular flow and a new calibration for off idle and cruising performance improved.
The design of the annular flow booster delivers fuel atomization improved to eliminate flat spots that may be encountered when the carburetor transitions from idle to full throttle.
Each annular flow booster features orifices eight, equally spaced to improve fuel metering from idle to the main circuit.
The flow metering improved makes this carburetor ideal for use with a variety of small-block and big-block engines with either dual- or single-plane intake manifolds.
The #19069 AVS2 Edelbrock includes both timed and full vacuum ports for ignition advance.
It comes with: Primary Metering Jets – .
101, Secondary – .
098; Metering Rods – .
070 x .
037; Step-Up Spring – orange (5" Hg).
Use our Carburetor Stud Kits #8008 or #8024 if needed.
Match with a variety of manifolds that include Edelbrock Performer, Performer EPS, RPM Air-Gap, Performer RPM, Torker II or other brands of similar design.
