The 12V HP625 Series Heavy Duty Air Compressor Kit consists of the HP625 Series Pacbrake HP10625H Air Compressor and the complete unloader block assembly kit with pre-built harnesses.
Kit Number HP10116 Pacbrake's 625 Series heavy duty Pacbrake Air Compressors are available in two pump head configurations: Vertical and Horizontal, and have a 100 percent duty cycle.
This kit includes the Pacbrake HP625 Series Air Compressor (Kit Number HP10625H) and the entire unloader block assembly kit with pre-built harnesses.
All that is needed is a mounting location, power, ground wire, and a pneumatic air line.
The compressor features a copper wire wound permanent magnet motor, an oil-less design, sealed bearings, a PTFE piston ring, a cast aluminum cylinder head, a hard anodized aluminum cylinder, and an aluminum sleeve.
Compressor Specifications: 12V DC, 100 percent duty cycle at 100 PSI, 3/4 HP, vertical head configuration.
Size is 11.5 inches x 6 inches x 9.5 inches or 293 mm x 153 mm x 242 mm (LxWxH).
Weight is 17.7 lbs.
