The next generation in Edelbrock carburetors is the AVS2 Series.
Featuring annular flow primary boosters, the AVS2 has a new calibration for off idle and cruising performance.
To eliminate flat spots that may be encountered when transitioning from idle to full throttle, the annular flow booster design delivers improved fuel atomization.
Each annular booster has eight equally spaced orifices to enhance fuel metering from idle to the main.
This carburetor is ideal for a wide variety of small-block and big-block engines with either dual- or single-plane intake manifolds.
The AVS2 includes both full and timed vacuum ports for ignition advance.
It comes with: Metering Jets - Primary .
101, Secondary .
098; Metering Rods - .
070 x .
037; Step-Up Spring - orange (5" Hg).
If needed, use carb Studs #8008 or #8024.
For the ultimate induction upgrade, match with an Edelbrock intake manifold.
