Fitment is perfect.
The LED Lightbar Kit for the 2019-2020 Ford Ranger from Diode Dynamics allows for mounting one 18 inch light bar in the bumper opening.
These brackets were designed specifically for the application and are CAD-designed to install using factory mounting points.
Cutting or drilling is not required!
Designed for performance, Diode Dynamics Stage Series light bars utilize optical simulation modeling for maximum functionality with compact size custom-engineered TIR optics and a useful beam pattern all in a highly durable package.
The high-intensity Lumileds LED chips are coupled with our U.S.
PATENT PENDING total internal reflection (TIR) optic, resulting in a total intensity that is significantly higher than a standard generic light bar using basic optics or reflectors.
Standard optics lose light internally and to glare, spreading light in every direction.
The TIR optic in the Stage Series collects all of the light from the LED and directs it only where needed, drastically reducing glare and enhancing total efficiency.
Functional patterns were designed with optical simulation modeling to shape the output in a highly-functional beam pattern.
Regardless of your auxiliary lighting needs, there is a Stage Series optic available.
The Combo pattern combines both Driving and Flood optics, shining light downrange in a focused rectangular 20Wx8H degree pattern while also illuminating the surrounding area in a full 80Wx50H degree spread.
The Stage Series 18 inch Combo Light Bar features a single flood lens in the middle with two driving lenses on the outer edges.
Proven reliability is a hallmark of Stage Series lighting, tested for long-term operation from -40 to 185 degrees F, vibration, moisture intrusion, and corrosion.
All tests are completed to SAE/DOT standards, similar to factory components.
They have also been tested on-road and are utilized by numerous rally and endurance racing teams for nighttime stages and laps.
