The car height information above is for reference only due to changes in camber values.
If you do not want the height of your car aimed at the calculated value, you will need to adjust the alignment with the actual vehicle.
Super Response Fluid and Low Vibration Spring have been adopted to give the best balance between running and riding experience ever before.
Inside, new parts are adopted to allow for a wide variety of settings in the dial, making it highly durable.
Set up the Fuji Speedway with ADVAN A052 (tires).
The dial has 12 front and 8 rear steps for good results, and this should be used as a reference when setting up.
The front camber value during testing is based on the adjustable upper arm.
Enjoy the evolution of HIPERMAX.
Vehicle height information (normal ratio) when shipped: F - 0.5 inches (12 mm), R - 0.6 inches (16 mm), Maximum Maximum - Lower Limit: F - 0.08 inches (2 mm) - 2.3 inches (58 mm), R - 0.0 inches (0 mm) - -2.4 inches (60 mm).
The adjustable range and lower limits in this case are not compliant with safety standards.
Limit to the lower limit: F - 0.08 - 2.3 inches (2 - 58 mm), R 0.0 - 2.4 inches (0 - 60 mm).
There is no body or arm interference; however, this may vary depending on the tire and wheel size.
