When the front case length is less than 8.3 inches (212 mm), arm lock is applicable.
The S15 is set using the latest theory.
By flexibly moving the suspension, tracking with the road improves, reducing wasted movement and enhancing the riding experience on the street.
Additionally, it is possible to actively move the load during sports rides, allowing the driver to feel the car's movement and enjoy safe control by suppressing sudden movement at the limit.
Recommended for beginners practicing in sports rides.
Due to its sporty nature, the rear-wheel drive vehicle emphasizes rear stability, and the product is set low underneath during shipping.
For those wanting to actively move the rear and oversteer, tightening the rear dial is suggested.
New parts inside have led to many changes in the dial, enabling a wide range of settings.
The front and back insulator spring is included for easier vehicle height adjustment.
Vehicle height information (normal ratio) when shipped: F - 1.9 inches (47 mm), R - 1.8 inches (45 mm), Maximum - Lower Limit: F - 2.9 inches (0 - 73 mm), R - 0.5 - 3.3 inches (12 - 85 mm).
The adjustable range and lower limits in this case do not comply with safety standards.
Limit to the lower limit.
F 0-73mm R -12-85mm.
No body or arm interference; however, this may vary depending on tire and wheel size.
