The BVA-200s is a tester for most battery and electrical systems.
Each test's information is stored, and the last 200 tests can be retrieved by displaying them on its LCD screen, downloading to the optional AC-22 infrared printer, or by downloading to a personal computer with the AC-12 PC adapter cable.
Rugged anodized aluminum housing makes this a durable unit.
The BVA-200s is a full-featured menu-driven battery tester and charging system analyzer that delivers quick, professional load results using Auto Meter's pulsed differential load.
Quick battery checks will increase productivity in charging.
The BVA-200s is user-friendly.
It indicates what to do.
The stator-diode test automatically shows open or shorted stator-diodes.
Its accuracy is professional.
Detailed test results are displayed on the LCD after each test or can be reviewed and/or printed from memory.
This hand-held tester is the auto industry's answer to portability in a professionally accurate battery load tester and system analyzer.
Each clamp's jaws must firmly engage the battery terminal.
The copper jaw contains the smaller gauge wire that reads the voltage, and the silver jaw contains the larger conducting wire that draws the load in each test.
Jaw insulation is necessary for accurate readings.
Damaged clamps or loose wires will affect readings.
Applications: 6V and 12V automotive and commercial starting batteries.
12V starting and charging systems.
Battery CCA range: 200-1600; automated load: 120 Amp; alternator test: Yes; stator diode test: Yes; starter draw test: Yes; external volt leads: No; voltmeter range: 0-30 with .01 resolution; voltage drop test: No; cooling: vented; digital display: 1" x 2.5" 4 line 16 character; operational temperature: 0-120 degrees F; operational humidity: 0-85%; language: English/Spanish; internal battery 9Vdc.
CAUTION: The BVA-200s grill may become hot after repeated use.
Be sure to hold the unit from the side grips only.
Keep hands away from the grill.
