The large offset FlexArm Joint from TeraFlex JK provides durability and articulation for off-road capabilities.
The chrome plated ball incorporates a smooth sliding surface to reduce bushing friction and heat buildup, extending maximum bushing life and providing extreme corrosion resistance.
Secure mounting is ensured by the increased shoulder width.
The urethane bushing features interlocking fingers that create a flow-through grease channel for proper lubrication to maximize bushing life.
Polyurethane material that dampens vibration reduces road noise, eliminates clunks, and maintains proper position for maximum articulation during travel.
The forged housing is CNC machined to exacting tolerances for durability and ultimate performance.
Zinc plating will maintain these tolerances for the rod end's life.
This FlexArm joint has an offset 10 degree 1-1/4 inch x 12 tpi right hand thread shank and accepts a 9/16 inch bolt.
Fits: JK Wrangler JKU Wrangler Unlimited Details: Small FlexArm Joint Shoulder Width: 2-5/8 inch Shank Size: 1-1/4 inch x 12 UNF Thread (Right Hand Thread) Shank Angle: 10 degrees Jam Nut Wrench: 1-7/8 inch Bolt Diameter: 9/16 inch (14mm) Forged Steel Housing Gold Zinc Plated Finish Sold individually SKU: 4116250
