Amperage: 6 Amps.
Length: 100 M.
Capacitance: 11.33 pf/ft.
+/- 10%.
Cable Shielding (3-levels): foil (overall), foil (power pair), foil (data pair).
Approvals: UL: plastic 75 dig C sunlight resistant E90625, AWM 80 dig C 300 volts, CSA: cmx-outdoor-cog ll54185 75 dig C, AWM I/II a/b 80c 300 volts FT4, NMEA: NMEA 2000 approved, IEC: iec-61162-3.
Applications: primarily used as drop cable, but it can also be used at the trunk line depending on network power requirements.
Bulk cable with field-attachable connectors allows for maximum flexibility as cables can be made on the job to exact lengths.
Color code: power pair: Red/black, data pair: white/Blue.
Impedance: 120 ohms +/- 10%.
Resistance/conductor: 18.1 ohms/1000'.
Packaging: 2 piece, 100 spool.
