The modular-inlet supercharger from Edelbrock is available for the 2015-17 Ford Mustang with a 5.0L Coyote engine.
The Edelbrock supercharger Kit W/O TUNER #158380 produces 690 horsepower and 588 ft-lbs of torque.
For owners of 2015-2017 Ford Mustangs with the 5.0L engine, the performance-proven modular-inlet supercharger is now available.
The new Edelbrock Supercharger System W/O Tuner #158380 is a bolt-on kit that produces 690 horsepower and 588 ft-lbs of torque.
At the heart of this system is Eaton's biggest R2650 TVS rotor assembly housed in a new manifold with an integrated high-capacity DP3C (dual-pass, three-core) air-to-water intercooler for lower inlet air temperatures and increased power potential.
The 170-degree high-twist lobes, bigger bearings, and beefier timing gears ensure maximum reliability with smooth acceleration throughout the powerband.
The supercharger for the 5.0L V8 fits under the stock hood with no cutting or modifications required.
If you're concerned about the effect on MPG, the increase in power comes with little to no loss in fuel economy thanks to the supercharger's integrated bypass valve that mitigates parasitic power loss during normal driving.
This new kit is a true bolt-on that requires no additional modifications to the stock Coyote engine.
For those wanting more power, an Edelbrock Stage 2 Upgrade Kit #15884 can be added to transform your Mustang into a track-ready beast!
The supercharger for the 2015-17 Mustang has a self-contained lubrication system with a 100,000-mile service interval and comes finished in a durable black powder-coating that blends nicely into the engine compartment.
Each kit includes a complete set of preformed hoses, hardware, and a full-color manual that provides clear step-by-step instructions for installation (Note: Kit #158380 does not include the handheld tuner).
This system is designed and manufactured in the USA and is covered by Edelbrock's industry-leading 3-year/36,000-mile warranty.
Manufacturer Edelbrock Application Application Specific UPC 00085347891054 System Type Stage 1 - Street System Vehicle Model Mustang Housing Material Cast Aluminum Gasket Or Seal Included Yes Quantity Kit Oil Capacity 150 mL Center Housing Cooling Type Intercooler Internal Step Up Yes Mounting Bracket Included Yes Outside Pulley Diameter 3.25 in CARB Executive Order Number D-215-107 Maximum Torque 588 ft-lb Fuel Injector Type 50 lb/hr Availability Note Available to Order Warranty 36 Months Horsepower 690 Emissions Code EO Number: D-215-107 Hazardous Materials Warning WARNING: This product can expose you to Chromium, which is known to the State of California to cause cancer or birth defects or other reproductive harm.
For more information, visit www.P65warnings.ca.gov.
Installation Notes Supercharger systems without tuners are not eligible for supplemental warranty and are only emissions-legal when used with the correct Edelbrock program.
For safety, the Edelbrock program retains the factory vehicle speed limiter setting.
Calibrations, Tuners, or Programs supplied with supercharger systems are only compatible with vehicles designed for use in the United States or Canada.
Edelbrock does not offer calibration support for any vehicle designed for use outside of the United States or Canada.
Finish Black Powder Coated Pulley Belt Width 6-Rib Universal Or Specific Fit Specific.
