696630-8 Manley

$1,066.42 USD

✓ No hidden fees — taxes included in the price & Free Shipping.

✓
Get 5% OFF Today
Use this coupon at checkout.
TRY5
Brand : Manley
Manley 696630-8 features BB-Chevy Inverted Dome Pistons with a 4.530'' bore.
Out of stock
Quantity :
Top Brands. Best Prices. Fast Shipping.

Discover quality parts and accessories for every adventure

Shop now before stocks run out — smart shoppers move fast!

Explore Now

Product Comparison We Made Easy For You

696630-8 Manley
696630-8 Manley
View Detail
Type
Pistons
Title
696630-8 Manley
Price
$1,066.42 USD
Vendor
Manley
Description
BB-Chevy Inverted Dome Pistons with a 4.530'' Bore (+.030'') and -20cc Dome Volume.548ci - 6.135'' Rod with 4.250'' Stroke (Std Deck) and 548ci - 6.535'' Rod with 4.250'' Stroke (Tall Deck).Compression Height is 1.520''.Technical Specs include Compression Ratio: 8.7:1 (112cc); 8.4:1 (118cc); 8.1:1 (124cc).Piston Weight is 700 grams with Inverted Dome Top: -20cc.Pin Size measures 0.990'' dia, 2.930'' long, .180'' wall (170 grams).Spiral Locks are .042'' wide (4 per piston) and Ring Grooves are 1/16'' Top; 1/16'' Middle; 3/16'' Bottom.Piston Clearance is .006'' measured 1.100'' from bottom of the oil ring and Valve Notch is .300'' Intake with Exhaust Valve: +.090''.

More about this item : 696630-8 Manley

BB-Chevy Inverted Dome Pistons with a 4.530'' Bore (+.030'') and -20cc Dome Volume.

548ci - 6.135'' Rod with 4.250'' Stroke (Std Deck) and 548ci - 6.535'' Rod with 4.250'' Stroke (Tall Deck).

Compression Height is 1.520''.

Technical Specs include Compression Ratio: 8.7:1 (112cc); 8.4:1 (118cc); 8.1:1 (124cc).

Piston Weight is 700 grams with Inverted Dome Top: -20cc.

Pin Size measures 0.990'' dia, 2.930'' long, .180'' wall (170 grams).

Spiral Locks are .042'' wide (4 per piston) and Ring Grooves are 1/16'' Top; 1/16'' Middle; 3/16'' Bottom.

Piston Clearance is .006'' measured 1.100'' from bottom of the oil ring and Valve Notch is .300'' Intake with Exhaust Valve: +.090''.

696630-8 Manley
Key Features
  • Manley Pistons
  • Compatible with Big Block 1.520 CD/ID 4.530
  • New in box
  • Actual Product may vary**
  • Piston Weight is 700 grams
  • Compression Height is 1.520''
Technical Specifications
  • Length : 9.0 lb
  • Width : 9.0 lb
  • Height : 7.75 lb
  • Weight : 10.0 lb
Product Identifiers
  • ASIN B00AZ6IOPC
  • UPC: 807298028828
Shipping Information
  • Ships From : United States
  • Brand : Manley

Frequently Asked Questions About : 696630-8 Manley

01 What is the bore size of Manley 696630-8?

The bore size is 4.530''.

02 What is the compression height of the pistons?

The compression height is 1.520''.

03 How much does each piston weigh?

Each piston weighs 700 grams.
