8566 Edelbrock

The Ford 429-460 head bolt kit includes the Edelbrock 8566 bolt kit, which contains a complete set of the highest quality head bolts and hardened washers available.

To ensure molecular integrity, cold-formed and heat treated prior to thread rolling and machining.

The reduced diameter bolt heads eliminate the need for valve train removal to facilitate cylinder head re-torqueing.

Included are hardened and parallel-ground washers.

Rated at 170,000 p.s.i.

Specs Application Universal GTIN 00085347085668 Emissions Code N/A Head Drive Type Hex Length 5.190 in Material Chromoly Installation Notes made specifically for big block Ford V8, use Edelbrock 7314 or Fel-Pro 1018 head gasket or equivalent.

NOTE For Performer RPM 460 (Non-CJ) heads, Edelbrock Cylinder Head Gasket Set 7365 may also be used.

This set includes all gaskets necessary for installation of Edelbrock cylinder heads including intake, exhaust, cylinder head, water neck and valve cover gaskets.

Follow the installation instructions for the head gasket.

Be sure that the surface of the block and the surface of the cylinder head is thoroughly cleaned to remove any oily film before installation.

Use alcohol or lacquer thinner on a lint-free rag to clean.

Apply engine oil to the head bolt threads, washer, and bolt where it contacts the washer.

The head bolt washers should be checked that they seat properly on the bolt under head, and not on the head bolt under head radius.

Torque the head bolt 135 ft./lbs.

in four steps following the factory tightening sequence.

A re-torque is recommended after initial start-up and cool-down (allow 2-3 hours for adequate cooling).

Install the intake manifold bolts lubricated with engine oil not exceeding 25 ft-lbs of torque when tightening.

It is also good practice to lubricate the exhaust manifold/headers bolt threads with a small amount of anti-seize paste.

Spark plugs.
