Replacement Parts by Edelbrock
Specifications for the cylinder head include: combustion chamber volume of 87cc; intake runner volume of 215cc; exhaust runner volume of 175cc; intake valve diameter of 2.
11"; exhaust valve diameter of 1.
66"; valve stem diameter of 11/32"; valve guides made of manganese bronze; deck thickness of 5/8"; valve spring diameter of 1.
46"; maximum lift for valve spring is .
575"; rocker stud measures 7/16"; guide plate is made of hardened steel; pushrod diameter is 5/16"; valve angle is 14°; exhaust port location is stock Ram Air IV; spark plug fitment is 14mm x 3/4 reach, gasket seat.
Designed for performance gains in 1962-79 389-455 c.
I.
d.
Pontiac engines, these cylinder heads are patterned after the 1969-70 Ram Air IV Pontiac cylinder head.
Performer heads #60579/#60575 are emissions legal for 1965-79 vehicles in all 50 states.
They feature combustion chambers of 87cc designed to maximize performance while using low-octane fuel with a streetable 9.
5: 1 compression ratio.
Performer RPM heads with 72cc combustion chambers are for higher compression engines.
Performer RPM #60509 is semi-machined and requires finishing by a professional cylinder head porter.
They include installed valve guides and seats with no intake pushrod holes.
Performer RPM #60587 is not port matched or bowl blended and is NHRA accepted for Stock & Super Stock.
INSTALLATION NOTE: These heads require Ram Air IV (round port) style exhaust manifolds or headers and Edelbrock head bolt kit #8549.
Deck thickness is 5/8", rocker stud diameter is 7/16", and pushrod diameter is 5/16" (width of slot in guide plate).
Will it fit your vehicle?
Compare the part number (EDL60575) and the specifications with your vehicle.
Ask us to check fitment- Authorized Edelbrock dealerNew, genuine, with the brand's own warranty.
- One honest priceShipping and tax included. Nothing added at checkout.
- Special order from the brandShips in 1–4 weeks, often sooner.
- Easy 15-day returnsUnused, in the original box. See the steps
A real person answers, Monday to Friday, 9 AM–6 PM EST.
Key features
87cc
215cc/175cc
2. 11 in./1. 66 in.
0.625 in.
11/32 in.
Specifications
Part # EDL60575
Specifications for the cylinder head include: combustion chamber volume of 87cc; intake runner volume of 215cc; exhaust runner volume of 175cc; intake…
- Free shipping to the lower 48
- Ships in 1–4 weeks
TryBeepbeep is an authorized Edelbrock dealer. Every Edelbrock part we sell is new and genuine, comes from the brand's U.S. distributors and is covered by Edelbrock's own warranty.
- Genuine Edelbrock part number (EDL60575)
- Brand warranty, handled with our help
- Same free shipping and tax-included price
Who you are buying from.
Free shipping
Compare
Frequently asked questions
About Cylinder Head Edelbrock 60575
01 What is the combustion chamber volume?
The combustion chamber volume is 87cc.
02 What is the intake runner volume?
The intake runner volume is 215cc.
03 What is the exhaust runner volume?
The exhaust runner volume is 175cc.
04 What is the UPC / barcode for this product?
The UPC/barcode for this product is 085347605750.
05 Where does this ship from?
Orders ship within the USA directly from our authorized U.S. distributor and brand warehouses.
06 How many days will it take to arrive?
This is a special order from the brand. Many special orders ship within a week, but some can take up to 3–4 weeks. Shipping is free in the lower 48, and we email you as soon as it ships. If the brand can't supply it, we cancel and refund you in full.
07 Does this product accept returns?
Yes — this item can be returned within 15 days of delivery for a free return by mail. See our return policy for full details.
