The new Coke-bottle design of '68 ushered in a new dashboard as well, and we're here to fill it up!
Get ready to bolt in a six-gauge instrument system without cutting up the dash!
Whatever is powering your 1968 Pontiac A-body, we've got you covered with supplied sensors for oil, water and speed, as well as our collection of BIM-expansion modules, available separately.
These VHX Systems fit directly into the stock Pontiac gauge carrier and include new clear lenses; the stock instrument lenses will no longer be used.
Speedometer 0 -160 MPH (optional metric version 0- 255 kmh) Tachometer 0- 8,000 RPM Oil Pressure 0- 80 psi Water Temperature 100- 260F (optional metric version 40- 120C) Fuel Level E, 1/4, 1/2, 3/4, F Voltmeter 9- 17 VDC Lighting Back lit technology is popular with performance instrumentation due to precise lighting allowing you see what is truly important when you really need it at a quick glance.
Each number, tick mark, annunciator, needle, indicator and digital message center is lit by a series of LEDs behind the gauge face.
Standard Displays Odometer (One time user settable, Million Mile), Dual (A/B) Trip Meter (0- 9,999.9), Clock (12 hour) Performance Meters 0- 60 MPH Timer (0- 100 kmh), 1/4 mile time, 1/4 mile end speed (trap speed), High speed recall, High RPM recall Gauges Speedometer (0- 255 MPH/kmh), Tachometer (0- 9,900 RPM), Oil Pressure (0-100 psi displayed in 1 psi increments), Water Temperature (100- 300F/ 40- 150C displayed in 1 F/C increments), Voltmeter (9- 17 VDC), Fuel Level (0-99% full) Lighting Auto-contrasting LCD display for optimal view in the brightest of sunlight, LED backlit at night to match/ complete the look at night.
