The 12V HP625 Series Heavy Duty Air Compressor Kit consists of the HP625 Series Pacbrake HP10625H Air Compressor and the basic components of the unloader block assembly.
This kit does not include the pre-built wiring harnesses.
The Pacbrake 625 Series Heavy Duty Air Compressors have a 100 percent duty cycle and are available in two pump head configurations: Vertical and Horizontal.
This kit includes the Pacbrake HP625 Series Air Compressor (Kit Number HP10625H) and the basic components of the unloader block assembly.
This kit does not include the pre-built wiring harnesses.
Compressor features include a copper wire wound permanent magnet motor, oil-less design, sealed bearings, PTFE piston ring, cast aluminum cylinder head, hard anodized aluminum cylinder, and aluminum sleeve.
Compressor specifications are 12V DC; 100 percent duty cycle at 100 PSI; 3/4 HP; horizontal head configuration.
Size is 11.5 inches x 9.5 inches x 6 inches or 293 mm x 242 mm x 153 mm (LxWxH).
Weight is 17.7 lbs.
