The in-cab control kit for independent air spring activation consists of a HP325 compressor, air spring dash switches, pre-built harnesses, fittings, fasteners, and everything required for a complete install.
This kit comes with everything needed to operate air springs or other pneumatic accessories right from the driver's seat.
Various dash activation switch kits are available depending on air spring operation requirements.
Simultaneous inflation is achieved with one switch that inflates or deflates both air springs together at the same time.
The kit consists of HP325 compressor, air spring dash switches, digital gauge for independent activation, pre-built harnesses, fittings, fasteners, and everything required for a complete install.
Air compressor specifications include 12 VDC, 100 percent duty cycle (1 hour at 100 PSI), 1.2 CFM, 150 PSI max operating pressure, and draws 18 amps.
Air tank options include a 1/2 gallon air tank (HP10053) or a 2 1/2 gallon air tank (HP10050).
Note that this is a complete kit with onboard air.
If adding an air tank, a pressure switch is required; HP10110 is for 105-135 PSI and HP10111 is for 85-105 PSI.
