The Premium In-cab Control Kit for simultaneous spring activation consists of a compressor HP325, dash switches for air springs, pre-built harnesses, fittings, fasteners, and everything required for a complete install.
This in-cab control kit comes with everything needed to operate air springs or other pneumatic accessories right from the driver's seat.
Depending on your air spring operation requirements, various dash activation switch kits are available.
Simultaneous inflation is achieved with one switch that inflates or deflates both air springs together at the same time.
The kit consists of HP325 compressor, air spring dash switches with a digital gauge for independent activation, pre-built harnesses, fittings, fasteners, and everything required for a complete install.
Air Compressor Specifications include 12 VDC, 100 percent duty cycle (1 Hour at 100 PSI), 1.2 CFM, and 150 PSI max operating pressure.
It draws 18 amps.
Air tank options include a 1/2 gallon air tank (HP10053) or a 2 1/2 gallon air tank (HP10050).
Note that this is a complete kit with onboard air.
If adding an air tank, a pressure switch is required; HP10110 is for 105-135 PSI and HP10111 is for 85-105 PSI.
Details: Simultaneous inflation, Application Universal, HP325 Series.
