Compatible with torque testing stand 89640 (not included).
Stores up to 5000 data points.
Accuracy of +/- 0.5% within 10% - 100% of full load value.
Easy menu operation on a 7" color touch screen.
7 torque measurement units provide a readout in in/oz, ft/lb, in/lb, Nm, cNm, kg/cm and Kg/m.
Data can be uploaded via a USB interface.
Designed for more detailed reporting with 3 interfaces; regular, preset and curve.
3 available modes track, peak, and first.
Automatically stores 15 tests readings while testing.
Overall Length: 3.
ANSI Specification: Meets or Exceeds ASME.
Specification: Meets or Exceeds.
Packaging: Boxed.
Weight (Catalog): 11.200.
Warranty: 90 Day Calibration/1 Year Parts.
Min Torque (Primary Scale): 10.
Max Torque (Primary Scale): 100.
Drive Tang Size: 1/2 in.
Min Torque (Alt Scale): 13.6.
Max Torque (Alt Scale): 135.6.
Torque Accuracy (20-100% of Full Range): +/-0.5%.
Clockwise Finish: Painted.
UPC: 099575896385.
Overall Height: 4.
Overall Width: 4.
Drive Type: Square.
Material: Steel.
